Sea Dog Marine 3 Position Switch (One Circuit) (420410-1)

Boating is an excellent way to release tension and escape from everyday life's stresses. Increase your enjoyment of time on the water with this excellent marine product. One circuit 3 positions push-pull switch (3-420410-1) by Sea Dog. Positions Three Push-Pull One-Circuit, the controller has a single circuit (which is generally disconnected) and three positions: Off/On/On. When the switch is completely inserted, it is turned off. The first circuit is activated when the lever is pushed to the first position. Both the first and second circuits are active in the second position.

Key Features:

• Rated at 15 amps at 12 volts direct current
• Action: Off/On/On Push-Pull Switch
• Off is the default position.
• 3/8" dia. x 1" long mounting stem
• Corrosion-resistant stamped brass construction.
• Excellent choice for the cabin or running lights.
• Exquisitely constructed from the finest materials
• Designed to adhere to stringent quality criteria

Specifications:

• Brand: Sea-Dog Marine
• SKU: 3-420410-1
• UPC: 035514420044
• Weight: 0.19 LBS
• A: 1"
• B: 3/8"
• Amps: 15 A at 12 V DC

420390-1 - Push-pull switch features positive actuation with two positions On-Off (normally Off). Stamped brass construction. Rated 15 amps @ 12VDC. 420410-1 - One circuit, normally off, three position: Off/On/On. Ideal for cabin or running lights.

This product replaces:

• 420410
• 420410-1
• 5-51305
• 3-420410
• 35514420044
