Futura - LED Driver - 120-277V, 18W (LED-18W-DC-700MAP)

Introducing the LED-18W-DC-700MAP Marine LED Driver, the perfect solution for your marine lighting needs. With a compact size of 1 2/16" x 1 1/2" x 5 2/16" and a weight of 10.58 ounces, this driver is designed to fit seamlessly into your marine lighting setup.

The LED-18W-DC-700MAP Driver has a wide input voltage range of 120-277V 50/60Hz, with an input current of 0.17A (120V) - 0.09A (277V). It also features an electronic internal resettable short circuit protection, thermal protection, and overload regulation, ensuring safe and reliable operation in harsh marine environments.

The driver is housed in an aluminum casing, providing robust protection against the elements, and is fully waterproof thanks to its waterproof potting. Its output wire is 18AWG Teflon, while the input wire is Fep/Fep 0.75mm2 450V 180ºC, ensuring reliable and long-lasting performance.

The LED-18W-DC-700MAP Driver is also dimmable, allowing you to adjust the brightness of your lighting as needed. Its output voltage range is 4-26V (Blue- Red+), with an output current of 700mA, providing ample power for a wide range of LED lighting applications.

With a maximum Tc of +80°C and a maximum Ta of -25°C to +50°C, the LED-18W-DC-700MAP Driver is designed to operate in a wide range of temperatures, making it perfect for use in marine environments. Its Pmax is 18VA, with an efficiency of 80%, THD max of 10%, and Harmonics of EN 61000-3-2.

The LED-18W-DC-700MAP Driver meets safety standards EN 61347-2-2 and immunity standards EN 61547 / 61047, and is SELV (Safety Extra Low Voltage) compliant, ensuring safe and reliable operation for all your marine lighting needs.
