Sea Star Solutions Ignition Switch - Mercury (Mp41000)

A marine ignition switch generates a spark in the engine cylinder, causing the engine to start. Push to choke with the OFF-RUN-START switch position on the IGNITION SWITCH- MERCURY from Sea Star Solutions. It is a magneto type with 6 screw tabs Terminal. Made with Marine-grade glass-filled polyester, the back up nut is brass, whereas the face nut is hex black plastic. It has a 7 Amp @ 12 VDC Choke, a 15 Amp @ 12 VDC Ignition, and a 30 Amp @ 12 VDC Solenoid for the Rated.

Key Features:

• This product also replaces 49-41000, MP41002, MP41000, 808282367701, 11-MP41000, 18-1804, AP1948, 2312141000, 23121410008, 9-15301
• Mercury 87-88107, 87-88107A5, 87-17393, Mercury 87-88107, 87-88107A5, Sea-Dog 420381-1 are interchangeable
• Maximum corrosion resistance - prevents oxidation with an inner seal between the cylinder lock and the contact plate
• Potential shorts are eliminated by employing non-conductive housing

Specifications:

• BRAND: Sea Star Solutions
• SKU: MP41000
• UPC: 023121410008
• WEIGHT: 0.25 LBS
• HOLE SIZE: 7/8"
• LENGTH: Short 5/8" maximum panel thickness

3 Position Magneto, Push to choke, Switch Positions: Off-Run-Start. Terminal Type: 6 screw tab, Material: Marine grade glass-filled Polyester

This product replaces:

49-41000, MP41002, MP41000, 808282367701, 11-MP41000, 18-1804, AP1948, 2312141000, 23121410008, 9-15301
