Raymarine eS7 Video In/NMEA 0183 Cable, For eS75/78, 2 m

Overview

The Raymarine R70414 is a 2 m Video In/NMEA 0183 cable for Raymarine eS7-series multifunction displays. It gives compatible eS displays the cable connection needed for video input and NMEA 0183 wiring, making it useful when adding a camera feed or connecting older NMEA 0183 equipment at the helm.

This cable is a practical accessory for installations where a display needs to accept an external NTSC/PAL video source or interface with NMEA 0183 data wiring. The open cable end gives the installer room to terminate the connections cleanly behind the dash, while the display-side connector keeps the connection matched to the Raymarine eS7 display port.

Key features

• Works with Raymarine eS7-series multifunction displays, including eS75 and eS78 display installations.
• Combines video input and NMEA 0183 connectivity in one cable for cleaner helm wiring.
• 2 m cable length gives useful routing distance behind a console or electronics panel.
• Supports connection of NTSC/PAL video input for compatible camera or video sources.
• Open cable end allows the installer to make the required NMEA 0183 and video terminations for the boat layout.

Installation and setup

Use this cable when the eS7 display installation needs a video input lead or a NMEA 0183 connection point. It is normally routed from the rear of the display into the helm wiring area, where the open end can be connected to the relevant video source or NMEA 0183 device wiring.

As with any marine electronics wiring, the cable run should be kept supported, dry where practical, and protected from sharp edges, strain, and service-access pinch points. Leave enough slack behind the display so the unit can be removed for inspection or future upgrades without stressing the connector.

Compatibility and fit

This cable is for Raymarine eS7-series displays rather than a universal video or network cable. It is a good match for owners or installers updating an eS helm station with a camera feed, a legacy NMEA 0183 device, or a service replacement cable for an existing installation.

Before ordering, confirm the exact display model and the required connection type at the helm. Boats with mixed electronics systems often use both newer networked equipment and older NMEA 0183 devices, so checking the existing wiring plan helps avoid ordering a cable that does not match the display port or installation goal.
