Imtra Mini GU4 LED Bulb, 10-30VDC, 1.5W, Cool White

Overview

The Imtra ILBPG4-09C is a compact Mini GU4 LED replacement bulb with a back-pin configuration, intended for marine fixtures using G4 bi-pin sockets. Operating on 10-30VDC with a power consumption of 1.5W, it produces 120 lumens of cool white light through nine surface-mounted LEDs, making it a low-power alternative to traditional halogen bulbs.

Its compact circular design fits small to medium-sized downlights, reading lights, and chart lights with back-pin sockets, including fixtures with narrow conical reflectors. A pulse-width modulation (PWM) constant-current driver maintains operation across the supported voltage range, while integrated electrical protections support long-term use.

Key features

• G4/GU4 bi-pin base with back-pin mounting configuration.

• 10-30VDC operating range for 12V and 24V DC systems.

• 1.5W power consumption with 120-lumen cool white output.

• Nine surface-mounted LEDs with a 120-degree beam angle.

• Compact 0.90-inch diameter and 1.04-inch overall length, including pins.

• PWM constant-current driver with integrated electrical protection.

• Equivalent light output to an approximately 10W halogen bulb.

Installation and compatibility

The bulb installs into compatible G4 bi-pin sockets with a back-pin orientation. Its compact dimensions accommodate fixtures with limited internal clearance, and the extended contact pins can be trimmed to suit the socket depth when necessary. Confirm the socket orientation, available clearance, and DC supply voltage before installation.

It is also compatible with Imtra DMS Series dimmers, subject to the applicable dimmer compatibility chart. Dimmer compatibility should be verified before use with an existing lighting control system.
