Imtra Mini G4 Side-Pin LED Replacement Bulb, 10-30VDC, Blue Light, 1.5W

Overview

The Imtra ILSPG4-09B is a Mini G4 side-pin LED replacement bulb that produces blue illumination for compact marine lighting fixtures. Operating on 10-30VDC with a power consumption of 1.5W, it uses nine surface-mount LEDs (SMDs) arranged in a compact, directional cluster. The bulb fits G4 side-pin sockets commonly found in small overhead lights and recessed fixtures aboard boats.

Its blue light output suits accent and courtesy lighting in side decks, aft cockpits, and towers. A PWM constant-current driver regulates LED operation across the supported voltage range, while integrated electrical and thermal protections help manage voltage fluctuations and operating temperature.

Key features

• 10-30VDC operating range compatible with 12V and 24V DC electrical systems.

• 1.5W power consumption with a 10W halogen equivalency rating.

• Nine SMD LEDs producing directional blue illumination.

• G4 side-pin connection for compatible marine lighting fixtures.

• Compact dimensions of 0.91 in (23 mm) x 0.37 in (9.35 mm).

• PWM constant-current circuitry for regulated LED operation.

• Integrated thermal protection, reverse-polarity protection, and transient voltage suppression up to 60V.

• Compatible with 12VAC supplied through a transformer.

Compatibility and fit

The Mini G4 configuration accommodates compact fixtures with side-entry G4 sockets, including small overhead lights and recessed spots. Its directional LED arrangement concentrates illumination toward the front of the bulb rather than distributing light equally in every direction. Socket orientation and available fixture clearance should be checked before replacing an existing halogen bulb.

Electrical integration

The wide DC input range supports installations using either 12V or 24V onboard electrical systems without requiring a separate voltage-specific bulb. The constant-current driver incorporates overvoltage protection, transient suppression, and automatic thermal rollback to manage electrical and temperature conditions during operation. The bulb also supports 12VAC operation when powered through a compatible transformer.
