Imtra LED AC to DC Converter, 90-264VAC, 24VDC, 100W, IP67

Overview

The Imtra IL-LED100WDC24V is a voltage-regulated AC to DC LED power converter that supplies 24VDC power from a 90-264VAC input. With a 100W nominal power capacity and a 47-63Hz input frequency range, it supports low-voltage LED lighting installations where AC line voltage is the available power source.

The converter maintains a regulated DC output for compatible LED equipment and incorporates short-circuit, over-voltage, over-current, and thermal protection. Its IP67-rated enclosure protects against dust ingress and temporary water immersion, allowing installation in suitable marine environments where moisture exposure is a consideration.

Key features

• Converts 90-264VAC input power to a regulated 24VDC output.

• 100W nominal power capacity for compatible low-voltage LED lighting systems.

• 47-63Hz AC input frequency range.

• IP67-rated enclosure for protection against dust and water ingress.

• Short-circuit, over-voltage, over-current, and thermal protection.

• Active power factor correction for AC power conversion.

• Approximate housing dimensions of 222.2 x 68 x 38.8 mm (L x W x H).

Electrical and system integration

The converter supplies regulated 24VDC power to LED lighting equipment that requires a DC source rather than direct AC input. Its wide AC input range accommodates different line-voltage supplies without requiring separate converters for individual input voltages within the supported range.

For installation, the connected lighting load must be compatible with the 24VDC output and remain within the converter's rated electrical capacity. Integrated electrical protections help manage abnormal operating conditions, including overloads and short circuits.

Installation and placement

The IP67-rated housing supports installation in marine lighting systems where exposure to moisture or dust may occur. The converter uses passive cooling, so placement should account for surrounding temperature and adequate heat dissipation. It is suitable for supplying compatible 24VDC LED fixtures from an available AC electrical circuit aboard a vessel.
