Imtra LED AC to DC Converter, 90-264VAC, 24VDC, 20W, IP67

Overview

The Imtra IL-LED20WDC24V is a voltage-regulated AC to DC power converter that supplies 24VDC to low-voltage LED lighting. It accepts a universal input of 90-264VAC at 47-63Hz and supports a maximum output of approximately 20W, with a rated output current of 0.84A.

The converter allows 24VDC LED lighting to operate from an AC power source without a separate DC supply. Its constant-voltage output helps protect connected lighting from voltage fluctuations, while integrated short-circuit, overload, and overvoltage protection address electrical fault conditions. The fully isolated plastic enclosure has an IP67 ingress protection rating.

Key features

• Converts 90-264VAC input power to regulated 24VDC output.

• Supports 47-63Hz AC input frequency.

• Rated output current of 0.84A with approximately 20W power capacity.

• IP67-rated enclosure with epoxy encapsulation for protection against dust and water ingress.

• Integrated short-circuit, overcurrent, and overvoltage protection.

• Resettable overcurrent protection automatically recovers after the fault condition is removed.

• Fully isolated plastic housing measuring 118 x 35 x 26 mm.

• UL 1310 Class 2 power unit classification.

Electrical and system integration

This converter is suitable for marine lighting installations where AC line voltage is available but the connected LED fixtures require a regulated 24VDC supply. The connected lighting load must remain within the converter's rated output capacity. It is intended for constant-voltage LED equipment rather than devices requiring a constant-current driver.

Installation and setup

The compact enclosure measures 118 mm long, 35 mm wide, and 26 mm high, allowing placement within lighting power distribution spaces. Separate AC input and DC output leads provide electrical connections, with polarity identified for the 24VDC output. Installation must maintain appropriate separation and protection for the AC supply wiring.

The IP67 enclosure protects the converter against dust ingress and temporary water immersion under rated test conditions. Operating temperature and available output capacity must be considered together, as the power supply requires load derating at elevated temperatures.
