Simrad HS90 Wired Handset & Speaker Kit, For RS90 VHF, IPX7, 5m Cable

Overview

The Simrad 000-11226-001 is an HS90 handset and RS90 external speaker kit for expanding a Simrad RS90 modular VHF system with another wired station. Both the handset and speaker are rated IPX7 (JIS-7), and the kit includes a 5 m (16.5 ft) handset cable for routing from the transceiver area to a helm, cockpit, or cabin station.

The HS90 handset gives full control of RS90 functions from that location, with a graphical display, an alphanumeric keypad, and shortcut keys for features like AIS plot, navigation, waypoints, and MOB. The external speaker boosts audio at the station, and its volume and on/off state are controlled from the paired handset.

This is a practical add-on when you want RS90 access at a second helm, near the companionway, or in the cockpit, without moving the primary station.

Key features

• Adds an additional wired station to a Simrad RS90 modular VHF system (not a standalone radio).
• HS90 handset with graphical display, alphanumeric keypad, and shortcut keys for AIS plot, navigation, waypoints, and MOB functions.
• IPX7 (JIS-7) waterproof rating for both the handset and the external speaker for exposed mounting areas.
• 5 m (16.5 ft) handset cable included; a 20 m (65 ft) handset cable is available separately for longer runs.
• RS90 system capacity: up to 6 stations total (4 wired and 2 wireless) and up to 4 external speakers (one per wired handset).
• Speaker mounting options include flush or surface mounting; speaker body dimensions are 110 x 110 x 45 mm (4.33 x 4.33 x 1.85 in).
• Operating temperature range: -20°C to +55°C (-4°F to 131°F).

What’s included

• HS90 wired handset
• RS90 external speaker
• 5 m (16.5 ft) handset cable
• Wired handset cradle

Compatibility and fit

This kit is for the Simrad RS90 modular VHF system and is intended to expand an existing RS90 installation. It is not used as a replacement for a fixed-mount VHF front panel, and it is not a universal remote for other VHF models.

If your boat is a 24 V vessel, plan the RS90 system supply accordingly since the RS90 system runs on 12 V DC. The handset station itself is powered through the RS90 system.

For space planning, the handset body is 69.0 x 200.5 x 50.0 mm (2.72 x 7.97 x 2.0 in) and mounts on a cradle, while the speaker needs room for either surface mounting or a flush cutout depending on your installation choice.

Installation and setup

The handset cable is meant to be routed cleanly through a bulkhead or dash using its connector assembly, so you can leave the transceiver wiring protected and keep the handset station tidy. When routing the cable, avoid tight bends, chafe points, and areas where it can sit in standing water.

The speaker can be placed where audio is most useful at that station, such as under a hardtop, near a helm console, or at a nav desk. Once connected, the handset can control RS90 radio functions at that location and participate in the onboard intercom and announcement features available within the RS90 system.

On-board use

On boats with more than one operating position, this kit helps keep VHF control where you actually stand watch. It also suits crews that want intercom between cockpit and cabin stations, with station audio that can be heard without everyone crowding around a single handset.

Maintenance and care

After saltwater runs, a light rinse and wipe-down helps keep the keypad, speaker grill, and cable connections clean. Periodically check the cradle mounting and cable pass-through points for loosening or chafe, especially on boats that see a lot of vibration.
