Imtra Resolux 873 Surface Mount LED Light, 24VDC, 9W, Dimmer, Warm White

Overview

The Imtra IL0480 is a Resolux 873 surface-mount LED light with an integrated dimmer switch, intended for interior marine lighting. Operating on 24VDC with 9W power consumption, it delivers warm white illumination with a rated output of 600 lumens. Its linear housing rotates through 270 degrees, allowing the light to be directed toward specific areas.

The fixture features a backlit momentary push-button switch for local dimming control, eliminating the need for a separate wall-mounted dimmer. Its white aluminum housing and acrylic lens provide a compact lighting arrangement for under-cabinet, vanity, and other dry interior installations.

Key features

• 24VDC nominal operation with 9W power consumption.

• Warm white LED output rated at 600 lumens.

• Integrated, backlit momentary push-button dimmer.

• 270-degree rotating housing for adjustable light direction.

• 58-degree beam angle for directed illumination.

• Integrated 10-30VDC driver electronics.

• White aluminum housing with an acrylic lens.

• IP40 ingress protection rating.

Installation and mounting

The surface-mount fixture measures approximately 24.37 inches (619 mm) in length, 1.22 inches (31.1 mm) in width, and 1.35 inches (34.3 mm) in height. Its integrated driver supports connection to a compatible DC electrical supply, while the built-in dimmer provides direct control at the fixture.

The IP40 rating provides protection against solid objects but does not indicate water resistance. Installation should therefore be limited to dry interior locations protected from water exposure.
