Engine Application

Evinrude/Johnson® 40-140 Horsepower 4.25” Gearcase

2 cyl: 50hp ('71-'74) / 45 to 55hp commercial;
3 cyl: 55, 60, 65, 70hp, 75hp with large gearcase, 65hp commercial;
4 cyl: 75, 85, 88, 90, 100, 110, 115, 120 ('86-'94), 125, 135 ('73-'76), 140 ('77-'84, '86-'94) / H.O. (includes E-TEC H.O.): 60, 90, 115hp;
E-TEC: 40, 50, 60, 65, 75hp / 20" shaft: 90, 115hp (not pontoon series), 130hp ('09-'10)4 stroke: 8hp ('96+), 9.9hp ('95-'01), 15hp ('95+)

Evinrude/Johnson® 60-70 Horsepower (4-Stroke) 4.25” Gearcase

4 stroke (Johnson): 60hp, 70hp

Force® 75-150 Horsepower (2-Stroke) 4.25” Gearcase

75hp ('99) / 90hp to 150hp ('95+)

Honda® 60-130 Horsepower (4-Stroke) 4.25" Gearcase

BF 4 Stroke: P60 / 75, 90 (‘99+) / 100, 115, 130hp. (not 115D)

Honda® 75-90 Horsepower (4-Stroke) 4.25" Gearcase

('95-'98): 75hp, 90hp

Johnson® 50-140 Horsepower 4.25” Gearcase

DF 4 stroke (Johnson): 50AV, 60AV, 115A, 140, 140A4 stroke: 8hp ('96+), 9.9hp ('95-'01), 15hp ('95+)

Johnson® 70-115 Horsepower (4-Stroke) 4.25” Gearcase

4 stroke (Johnson): ('09+): 70A, 80A, 90A, 70, 80 / ('01+): 90, 100, 115 (Not 115A)

Mercury®, Mariner® 40-150 Horsepower 4.25" Gearcase

Note: Props Not Available for '77 & Older models.
(2 & 4 stroke) 40 to 60 Bigfoot / 70 ('87-'89) / 75, 80 ('78-'89), 90, 100, 115, 125, 140hp / 150 XR4/6 (thru 1993, includes equivalent Mariner Magnum I, II, III.)
FourStroke™ & SeaPro™ 4cyl: 40 to 75hp / OptiMax: 75, 90, 115, 125hp

Omc 1.6-3.Ol+ Horsepower 4.25" Gearcase

Cobra 400: 2.3 to 3.0L (‘78-’89) / Sea Drive: 1.6 to 1.8L

Parsun® 60-90 Horsepower 4.25” Gearcase

T60, T75, T85, T90

Suzuki® 50-140 Horsepower 4.25” Gearcase

DF 4 stroke: 50AV, 60AV, 115A, 140, 140A

Suzuki® 60-140 Horsepower 4.25” Gearcase

DT 2 Stroke (‘89+): 75 to 140hp / DF 4 Stroke (‘98-’09): 60hp, 70hp

Suzuki® 70-115 Horsepower 4.25” Gearcase

4 stroke: (‘09+) 70A, 80A, 90A, 70, 80 / (‘01+) 90, 100, 115 (Not 115A)

Tohatsu® Nissan® 60-115 Horsepower (2 & 4-Stroke) 4.25” Gearcase

60C, 70C, 70 (‘02-’09) / (Not BFT): 90 to 140hp / 115hp TLDI (‘14+)

Tohatsu® Nissan® 60-90 Horsepower (2 & 4-Stroke) 4.25” Gearcase

BFT ('14+): W60, 60, 75, 90hp

Yamaha 50-100 Horsepower 4.25” Gearcase

Note: If prop strikes trim tab, replace with Yamaha part #6E5-45371-10.
High Thrust: FT50, FT60 / 2 stroke: 60 to 100hp / 4 stroke: 70, 75 (‘03-’16), 80, 90 (‘03-’16), 100hp

Yamaha 75-130 Horsepower 4.25” Gearcase

Note: If prop strikes trim tab, replace with Yamaha part #6E5-45371-10.
2 stroke: 115 to 130hp / 4 stroke: 75 (‘17+), 90 (‘17+), 115hp

This product replaces:

• 652480206658
• EX2-1411-4
• EX1-1411-4
