Overview

The Garmin HXAW003R is an Indian Subcontinent coastal chart region in the BlueChart g3 family, available as standard BlueChart g3 or BlueChart g3 Vision in SD card or download formats.

Coverage runs from Pasni, Pakistan, to Sandoway, Myanmar, with additional coverage for Sri Lanka, the Andaman and Nicobar Islands, the Chagos Archipelago, and the Maldives (excluding detailed coverage of the Male Atoll). A number of detailed charts are included for areas such as Mangalore, Quilon, and Calcutta.

On board, it adds chart detail that you can use for route planning and day-to-day navigation, including navigation aids, spot soundings, depth contours, tides and currents, and detailed harbor and marina information.

Key features

• Regional coverage for the Indian Subcontinent from Pasni (Pakistan) to Sandoway (Myanmar), plus Sri Lanka, Andaman and Nicobar Islands, Chagos Archipelago, and the Maldives (excluding detailed Male Atoll coverage)
• Includes detailed charts for areas such as Mangalore, Quilon, and Calcutta
• Chart layers include navigation aids, spot soundings, depth contours, tides and currents, and detailed harbor and marina information
• Depth Range Shading supports up to 10 depth ranges so you can highlight depths that matter for your draft
• Supports shallow water shading at a user-defined depth, and up to 1-foot contours where the chart data supports it
• BlueChart g3 Vision adds extra chart presentation features such as 3D views, relief shading, and aerial photos where available
• Download format installs to a microSD/SD card using Garmin Express, and only one chart can be installed to a single microSD/SD card
• Requires a compatible Garmin chartplotter or marine handheld that supports BlueChart g3 charts and accepts microSD/SD media

Variants

This chart region is offered in multiple configurations to match the chart feature set you want and how you prefer to receive the map.

The options vary by BlueChart version (BlueChart g3 or BlueChart g3 Vision) and by format (SD card or Download). BlueChart g3 Vision includes additional visual layers and views where available, while standard BlueChart g3 focuses on core charting detail.

• 010-C0755-20: BlueChart g3, SD Card. Supplied on physical media for chartplotters that use microSD/SD chart cards.
• 010-D0341-00: BlueChart g3, Download. Installs to your microSD/SD card through Garmin Express for use in a registered compatible chartplotter.
• 010-C0755-00: BlueChart g3 Vision, SD Card. Adds the Vision feature set while keeping the convenience of a physical chart card.
• 010-D0378-00: BlueChart g3 Vision, Download. Provides the Vision feature set via a download that you load to a microSD/SD card using Garmin Express.

Compatibility and fit

This is cartography for Garmin marine units that read BlueChart g3 charts. If your helm has more than one display, confirm which unit will hold the chart card, and make sure the unit you plan to use supports the BlueChart g3 format for supplemental charts.

The SD card variants are intended for systems with a microSD/SD chart slot. If your plotter uses its card slot for other tasks (logging, sonar recordings, software updates), plan for how you will dedicate or rotate cards when underway.

Installation and setup

For the SD card variants, insert the chart card into the chartplotter and select the chart source in your chart menu if your unit offers multiple map sources. The chart data stays on the card, so the card needs to remain installed while you want to view the HXAW003R region.

For the download variants, the chart is installed to a microSD/SD card using Garmin Express, then that card is used in the chartplotter. Only one chart can be installed to a single microSD/SD card, so dedicate a card to this region.

Use cases on board

This region makes sense for boats cruising the Indian coastline, running between India and Sri Lanka, or planning offshore legs that involve the Maldives and nearby island groups covered by HXAW003R. It is also a practical fit for skippers who want chart coverage on the same Garmin screen they use for routes, AIS targets, and situational awareness at the helm.

Maintenance and care

Chart cards live in a harsh environment. Keep the card contacts clean and dry, store the card in a protective case when not in use, and avoid handling it with wet or salty hands so the card slot stays reliable over time.
