Blue Sea E-Series Battery Switch 1-Off-2-Both 9001e-BSS

(No reviews) Write a Review

$63.99

SKU: APL419026

MPN: 9001e-BSS

UPC: 632085900151

Description
Specifications
Shipping & Returns
PDF
Videos

Description

Blue Sea Systems e-Series Selector Battery Switch

Model: 9001E-BSS

350 Amps continuous rating for inboard gasoline or diesel engines.
Tin-plated copper studs for maximum conductivity and corrosion resistance
Accepts up to 4/0 AWG battery cables
Studs accepts 3/8" (M10) ring terminals
7/8" (22mm) stud length accepts multiple cable terminals
Blue Sea Systems one-piece terminal stud design never loosens over time
Fits most Perko and Guest low amperage battery switch hole patterns
Case design allows surface or rear panel mounting
Tactile indicator conveys knob position by feel
Waterproof — rated IP66 from water projected in powerful jets
Ignition protected—safe for installation aboard gasoline powered boats
Make-before-break contact design allows switching without power interruption

Switches isolated battery banks to all loads or combines battery banks to all loads

Specifications

Switch Type	Selector 4 Position
Color	Red
Switch Positions	4
Battery Combine	Yes
Alternator Field Disconnect	No
Maximum Voltage	32V DC
Terminal Stud Torque	140 in-lb (15.82 Nm)
Continuous Rating	350A
Intermittent Rating	600A (5 min)
Cranking Rating 30 sec	1200A per circuit
Battery Inputs	2
Cable Clearance For 4/0 AWG Cables	1.10in (27.94 mm)
Cable Size to Meet Ratings	4/0 AWG (120mm )
Mounting Holes	Accept 1/4" (M6) Screw
Stud Material	Tinned Copper
Terminal Stud Size	3/8" - 16 (M10)

Video

PDF

Specifications
