Overview

The Simrad 000-10466-001 is a gimbal mounting bracket for installing an NSS12 EVO2 or B&G ZEUS2-12 12-inch multifunction display on a flat surface at the helm.

It is a practical choice when you want bracket mounting instead of a flush cutout, or when you are replacing a bracket that has been damaged or misplaced. The display angle is set and held with the correct side knobs, which are sold separately.

Key features

• Intended for Simrad NSS12 EVO2 and B&G ZEUS2-12 displays in a gimbal style mount
• Supports tilt adjustment when used with the matching locking knobs (knobs not included)
• Lets you mount a 12-inch display without cutting a new dash opening for a flush install
• Provides a stable mounting point for helms that see vibration, spray, and regular use
• Useful as replacement hardware for compatible factory bracket installations

Compatibility and fit

This bracket matches the mounting points used on NSS12 EVO2 and ZEUS2-12 gimbal installations. If your display is a different size or series, confirm the bracket part number for that unit before ordering.

Installation and setup

Mount the bracket to a solid, flat surface with suitable marine fasteners and backing. Leave clearance for the unit to tilt through its range and for the cable connections behind the display so connectors can bend without strain or chafe.

On boats that live in saltwater, rinsing salt off the bracket and hardware during routine washdowns helps keep the mount operating smoothly over time.

Use cases on board

This mount makes sense for center consoles, pilothouses, and nav stations where the display needs to be easy to view from both seated and standing positions, and where access behind the unit for wiring and service matters.
