Overview

The Vimar Idea 16786 Classica cover plate is a 1-module technopolymer plate for panel mounting, available in Bright White, Black, Idea White, and Graphite Grey. It measures 40 x 80 mm with an 8.9 mm depth, mounts horizontally or vertically, and uses clamp fastening with a mounting grid.

This plate is made from halogen-free thermoplastic with a glossy surface and includes a label space or information area on the face. It is suitable for built-in installation, wall duct, and subfloor installation duct box layouts where a single module needs a clean finished surround.

On board, it makes sense in protected interior areas such as cabin switch panels, helm consoles under cover, utility spaces, and other enclosed locations where appearance and clear labeling matter. With an IP00 rating, it is better suited to sheltered installations than exposed positions that take spray or washdowns.

Key features

• 1-module cover plate for Vimar IDEA panel-mount installations
• 40 x 80 mm overall size with 8.9 mm depth
• Horizontal or vertical mounting options
• Clamp mounting with mounting grid included in the assembly
• Label space or information surface on the front
• Halogen-free thermoplastic body with glossy finish
• Suitable for built-in installation, wall duct, and subfloor installation duct box use
• IP00 rating for protected interior mounting areas

Variants

This cover plate is offered in multiple color configurations within the same 1-module Classica format.

Across the range, the changing attribute is color. The core layout stays the same with 1-module panel mounting, horizontal or vertical installation, clamp fastening, mounting grid, label space, and the same 40 x 80 mm footprint with 8.9 mm depth.

• VM16786.01: Color Bright White. This finish works well with light switch surrounds and clean white interior panels.
• VM16786.16: Color Black. This finish keeps the plate visually quieter on dark helm panels, switch banks, and black trim pieces.
• VM16786.04: Color Idea White. This is a warmer white tone that can sit differently from Bright White when matching existing Vimar trim.
• VM16786.15: Color Graphite Grey. This darker neutral tone fits grey and anthracite panel schemes without drawing much contrast.

Compatibility and fit

This plate is intended for single-module panel applications in the Vimar IDEA range. The horizontal and vertical mounting options help when space is tight behind a console or when a panel layout needs to follow the direction of other switches and controls.

For marine refit work, the key fit checks are the 1-module format, the 40 x 80 mm outer size, and the protected mounting location. That makes it a practical match for interior electrical panels where a finished faceplate and a place for labeling are both useful.
