Raymarine Axiom 12 Adapter Plate, For C12x/e12x Displays, Black Finish

Overview

The Raymarine A80528 is an adapter plate for installing a Raymarine Axiom 12 multifunction display where a C12x or e12x Series display was previously fitted. It is made for retrofit work at the helm, giving the new 12-inch display a clean mounting face while using the existing fixing holes from the legacy installation.

This plate is useful when upgrading navigation electronics without recutting the dash more than necessary. The powder-coated black finish matches the Axiom display, so the installation looks intentional on a console, flybridge panel, or enclosed helm rather than patched over after the old unit is removed.

Key features

• Fits Raymarine Axiom 12 multifunction displays when replacing a C12x or e12x Series display.
• Uses the existing fixing holes from the C12x or e12x installation, helping reduce extra dash work during a retrofit.
• Adapter plate format covers the legacy opening area for a cleaner finished look at the helm.
• Powder-coated black finish matches the Axiom display and suits visible helm installations.
• Works as a practical mounting accessory for refits on cruising boats, fishing boats, and other vessels updating older Raymarine navigation displays.

Installation and fit

This is a mechanical mounting accessory, not an electrical interface. It does not change the display wiring, network setup, transducer selection, or power requirements of the Axiom 12. Before installation, the existing cutout and helm surface should be checked against the display installation requirements so the new unit has proper support, cable clearance, and service access behind the panel.

The plate is most relevant for boats already equipped with a Raymarine C12x or e12x display where the owner wants to move to an Axiom 12 while keeping the dashboard work controlled. It helps make the refit look tidy without turning the upgrade into a full helm rebuild.

Use cases on board

For coastal cruising, offshore fishing, and general navigation refits, this adapter plate helps keep an electronics upgrade focused on the new display and system integration rather than cosmetic repair around the old opening. It is a good match for owners, installers, and yards replacing legacy Raymarine hardware with an Axiom 12 at a fixed helm station.
