Overview

The Garmin 010-12234-01 is a flush-mount kit for echoMAP 9Xsv series chartplotters, letting you recess a 9-inch display into a helm panel for a low-profile install.

Use it when you want the unit sitting tight to the dash instead of on a bracket, with the bezel framed cleanly in the panel. The included template helps you lay out the cutout, and the hardware secures the chartplotter from behind the panel.

Key features

• Flush-mount kit for Garmin echoMAP 9Xsv series 9-inch displays.
• Sets the chartplotter against a flat panel face to reduce snag points at the helm.
• Template-guided cutout layout for a cleaner fit around the bezel.
• Mounting hardware and installation instructions included for the flush-mount process.
• Best suited to installs with rear clearance for connectors, cable bends, and access to tighten hardware.

What's included

• Cutout template
• Mounting hardware
• Installation instructions

Compatibility and fit

Compatible with Garmin echoMAP 93sv, echoMAP 94sv, echoMAP CHIRP 92sv, echoMAP CHIRP 93sv, echoMAP CHIRP 94sv, and echoMAP CHIRP 95sv units.

Confirm the exact model number on your display before ordering, then check that the mounting location is flat and has enough space behind it for connectors and strain relief on the cabling.

Installation and setup

Use the template to mark the cut line and any fastener locations, then dry-fit the unit before final fastening. If your dash is cored fiberglass, seal the exposed core at the cut edge so water cannot wick into the laminate.

On open helms and center consoles, a small bead of marine sealant around the cutout perimeter helps keep spray and washdown water from migrating behind the panel. Tie down the harness behind the dash so vibration does not pull on the connectors over time.

Electrical and system integration

This kit is strictly for mounting, so it does not change the power or data connections used by your echoMAP unit. Plan cable routing and connector clearance before you cut the panel.

On-board use

This mounting style suits boats where the screen is viewed from the helm and the back of the dash is accessible for service. It is especially useful when you want a clean console and fewer protrusions around the display.

Regulatory note

This product carries a Proposition 65 warning for California residents.
