Overview

The Garmin BlueChart g3 Vision HD VEU454S is a coastal electronic chart region for the Barcelona and Valencia area, covering from Port de Bouc, France to Cabo de Palos, Spain, including the Islas Baleares. It loads directly on a compatible Garmin chartplotter and adds detailed cartography plus photo and 3D views that help when you are running unfamiliar shorelines and port entrances.

Beyond the base chart layer, it includes Auto Guidance using your selected depth and overhead clearance, Depth Range Shading with up to 10 depth ranges, and Shallow Water Shading at a user-defined depth. Bottom detail is shown with contours as fine as 1 foot in supported areas, and the Vision layer adds high-resolution satellite imagery, aerial photos, FishEye View, and MarinerEye View for a more lifelike picture above and below the waterline.

Key features

• Region VEU454S: Barcelona and Valencia, from Port de Bouc (France) to Cabo de Palos (Spain), including the Islas Baleares
• Auto Guidance calculates a suggested route based on your entered depth and overhead clearance
• Depth Range Shading for up to 10 depth ranges to highlight target depths quickly
• Shallow Water Shading at a user-set depth limit for hazard awareness
• Bottom contours up to 1 foot in supported areas for clearer structure detail
• High-resolution satellite imagery and aerial photography for coastline and harbor recognition
• FishEye View and MarinerEye View add 3D perspectives for situational awareness

Variants

This chart region is offered in two formats, depending on how you prefer to load charts on board.

The chart content and coverage area remain the same across formats. What changes is delivery and setup: a preprogrammed microSD/SD card that you insert into the plotter, or a downloadable version that is installed to a microSD/SD card for use in a single compatible chartplotter.

• 010-C0798-00: Format microSD/SD. Insert the preloaded card into the chartplotter card slot to access the chart region, which is handy if you swap charts between trips.
• 010-D0468-00: Format Download. Install the chart to a microSD/SD card using Garmin Express on a computer, then move the card to the chartplotter for use on the water.

Compatibility and fit

This is a Garmin chartplotter chart region, not a standalone app. Confirm your plotter supports BlueChart g3 Vision and that you have an available card slot for microSD or SD, depending on your device and card adapter setup.

Some chart features (such as Auto Guidance and certain 3D/photo layers) depend on chartplotter support and software level. If you run multiple displays on board, verify which unit the card will live in and how your helm layout handles chart sources.

Installation and setup

For the microSD/SD card format, power the chartplotter down, insert the card fully, then restart and select the chart region in the chart menu. Keep the card installed while using the charts.

For the download format, plan on using a computer to write the chart to a microSD/SD card before heading to the dock. Use a clean, reliable card and leave the chart card in the chartplotter whenever you need access to this region.

Use cases on board

This chart is a good match for skippers cruising the western Mediterranean coast around Barcelona and Valencia, as well as anglers working depth breaks where contour detail and depth shading matter. It is also helpful for harbor approaches when satellite imagery and aerial photos make it easier to match what you see on screen to what is in front of the bow.
