Overview

The Garmin BlueChart g3 Alborg to Amsterdam is an electronic chart region covering the run from Aalborg Bugt to Amsterdam, including Limfjorden, Hamburg, Bremen, and Emden.

This chart family includes route-planning tools like Auto Guidance (based on your entered depth and overhead clearance), Depth Range Shading for up to 10 depth ranges, and up to 1 ft contours to help you read bottom shape and tight harbor approaches. It is available either on a pre-programmed microSD/SD card or as a download that gets written to a microSD/SD card through Garmin Express.

Within this region, the standard BlueChart g3 version is labeled HXEU019R, and the BlueChart g3 Vision version is labeled VEU019R. Both are intended for use on compatible Garmin chartplotters, and Vision content requires a display that supports the additional Vision layers and views.

Key features

• Coverage for Aalborg Bugt to Amsterdam, including Limfjorden, Hamburg, Bremen, and Emden
• Auto Guidance route planning using your chosen depth and overhead clearance settings
• Depth Range Shading for up to 10 depth ranges to highlight target depths at a glance
• Up to 1 ft contours for added bottom detail in port plans, canals, marinas, and nearshore areas
• Shallow Water Shading with a user-set depth threshold to help spot skinny water on the chart
• Chart content built from integrated Garmin and Navionics data
• Offered as BlueChart g3 (HXEU019R) or BlueChart g3 Vision (VEU019R), depending on the chart detail level you want
• SD card option for plug-in use, or download option installed to a microSD/SD card via Garmin Express (one chart per card)

Variants

This chart region is offered in multiple configurations.

The differences are the chart version (BlueChart g3 versus BlueChart g3 Vision) and the format (pre-programmed SD card versus download). The BlueChart g3 version for this area uses the HXEU019R label, and the Vision version uses the VEU019R label.

• 010-C0776-20: BlueChart g3 (HXEU019R), SD Card. Supplied on a pre-programmed card that you insert into a compatible Garmin chartplotter.
• 010-D0362-00: BlueChart g3 (HXEU019R), Download. Installed to a microSD/SD card using Garmin Express and unlocked to a specific compatible device.
• 010-C0776-00: BlueChart g3 Vision (VEU019R), SD Card. Uses the Vision version of this region, which can add extra chart layers and views when supported by your chartplotter.
• 010-D0447-00: BlueChart g3 Vision (VEU019R), Download. Installed to a microSD/SD card using Garmin Express and unlocked to a specific compatible device.

Compatibility and fit

This product is for compatible Garmin chartplotters that read BlueChart g3 cartography from a microSD/SD card. If you are running more than one display on a Garmin marine network, the chartplotter that holds the mapping card can share that chart data to other compatible networked units.

BlueChart g3 Vision features are not supported on every chartplotter. If your unit does not support Vision layers, the standard BlueChart g3 option is the safer match for this region.

Installation and setup

For the card format, installation is as simple as inserting the chart card into the chartplotter card slot and selecting the map layer on the unit.

For the download format, plan on using a computer with Garmin Express to write the chart to a microSD/SD card. Keep that card dedicated to this region, since only one chart can be installed per card.

Use cases on board

This region is a practical fit for skippers cruising or delivering between Denmark and the Netherlands, or making coastal and inland transits that pass through the approaches to Hamburg and Bremen. It is also a good match for boats that do frequent harbor work in the area and want tighter bottom detail and depth-focused shading on the plotter.
