Overview

The Vimar Supernova Series 2P+E German axial outlet is a portable 16 A, 250 V SICURY socket outlet for German standard connections, with axial cable entry and a screwed terminal connection. It uses the Type F CEE 7/3 outlet format and an IP20 housing, so it suits interior spaces on board that stay dry and protected.

This outlet fits portable AC cord sets and accessory connections where the vessel or dockside setup uses the German plug standard. The body is made from thermoplastic material and is halogen-free, and the straight cable entry helps keep the cord aligned with the outlet body when space is limited behind joinery or inside a locker.

Key features

• Portable 2P+E SICURY socket outlet in the German standard Type F CEE 7/3 format
• 16 A, 250 V rating for AC circuits built around this outlet pattern
• Axial cable entry with straight insert direction for inline cord routing
• Screwed terminal connection for wire termination and service work
• Thermoplastic body with halogen-free material
• IP20 protection for interior spaces that stay dry and protected

Variants

This outlet is offered in two finish options.

Across the range, the electrical format stays the same: portable 2P+E German standard outlet, 16 A, 250 V, axial cable entry, straight insert direction, screwed terminal connection, thermoplastic body, halogen-free material, and IP20 protection. The visible change between variants is the finish color.

• VM00250.B: White. This finish sits more quietly on light interior panels, cabinet sides, and white cord sets.
• VM00250: Black. This finish blends more easily with dark trim, utility spaces, and black cable runs.

Compatibility and fit

This outlet is built around the German 2P+E format. Before ordering, check that your plug pattern matches the Type F outlet layout and that your circuit is set up for 250 V service at the required current. It suits boats with European AC equipment, interior service leads, or dockside accessories that use this outlet style in enclosed areas.

Installation and setup

The screwed terminal connection is useful when terminating a new cord end or replacing a worn outlet on an existing lead, and the axial cable entry keeps the cable exit straight for a tidy run. Because protection is IP20, this outlet belongs in cabins, enclosed helm spaces, utility lockers, or other locations that stay dry and protected from spray and washdown.
