Vimar Plana 4-Module Cover Plate, 2+2 71mm Centers, Clamp Mounting
Overview
The Vimar Plana Series is a 4-module (2+2) cover plate with 71 mm distance between centres for finishing Vimar Plana modular switching and outlet points on board. The plate measures 151 mm wide by 80 mm high, with a 9 mm depth, so it helps you confirm fit before you pull trim or rework a panel cutout.
It clips in place with a clamp mounting system and can be installed horizontally or vertically, which is helpful when you are matching existing bulkhead layouts in cabins, nav stations, or service panels. This plate is rated IP00, so it should be used in protected locations or behind a suitable enclosure when the area can see spray or washdowns.
Key features
- 4-module cover plate in a 2+2 layout with 71 mm centre spacing
- Overall size: 151 mm width, 80 mm height, 9 mm depth
- Clamp mounting for a clean finish without visible screws
- Mounts horizontally or vertically to suit panel layout
- Halogen-free thermoplastic construction for everyday onboard use
- With mounting grid and label space for clearer circuit identification
- Suitable for built-in installation, wall duct systems, and subfloor duct boxes
- IP00 rating for use in dry, protected areas
Variants
This cover plate is offered in a wide range of colours and finishes so you can match existing Plana hardware or keep a refit consistent across cabins and control panels.
Across the range, the 4-module (2+2) format and 71 mm centre spacing remain the same, while the visible finish changes, including classic solids, matte metallic looks, metallized finishes, and Reflex colour effects. An antibacterial-treated white option is also available for areas that see frequent touch.
Compatibility and fit
This plate is for the Vimar Plana modular system in the 4-module (2+2) format with 71 mm centres. Before ordering, confirm the Plana mounting support behind the plate and the module layout at the installation point, especially when replacing older plates where centre spacing can differ.
Installation and setup
Install after the mechanisms are secured and aligned. Engage the plate evenly so the clamp points seat cleanly, then check that the edges sit flat against the surface with no twist. If you are mounting on a boat panel that flexes, make sure the support and box are firm so the plate does not work loose with vibration.
Use on board
This style of cover plate is commonly used for interior switch groups, outlet points, and control clusters where a tidy finish matters and access is easy. It suits yachts and refits already using Vimar Plana modules, especially when you need a specific colour match across multiple panels.
Maintenance and care
Wipe with a soft cloth and mild soap solution. Avoid aggressive solvents that can haze or mark thermoplastic finishes, and keep the installation out of direct UV exposure where possible to maintain the appearance over time.
